Best Testing: Asetek Simsports™ Pedal Set Pagani Huayra R Edition Review Tested by Our Team

Introduction

The Asetek SimSports™ Pedal Set Pagani Huayra R Edition is a premium sim racing pedal set that brings the exhilarating feel and aesthetic of a Pagani Huayra R supercar directly to your simulator cockpit. This officially licensed pedal board is developed collaboratively by Asetek SimSports and Pagani Automobili, designed to closely replicate the real car’s throttle and brake pedals. It combines cutting-edge mechanical engineering and high-end materials, making it an appealing option for serious sim racers.

Unboxing & First Impressions

Upon opening the box, the Asetek SimSports™ Pedal Set makes an immediate impression of luxury and quality. The packaging includes:

• Brake and throttle units
• Mounting hardware (M6 bolts, T-nuts, washers)
• Extra elastomers
• Additional springs
• USB-C cables for PC connectivity

The aluminum baseplate, complete with an integrated heel rest and RGB lighting, is branded with the iconic Pagani logo. This attention to detail sets the pedal set apart visually from many other options on the market.

Build Quality & Materials

Premium Motorsport-Inspired Construction

Every element of the Asetek SimSports™ Pedal Set exudes quality:

• Solid Aluminium Baseplate & Arms: All structural components, from the baseplate to the pedal arms and footplates, are CNC machined from anodized aluminum, ensuring both rigidity and durability.
• Hydraulic T.H.O.R.P Brake System: The brake features Asetek’s Twin Hydraulic Opposing Rapid Piston system, providing a two-stage racing feel with minimal travel and electrical pressure sensing up to 100 bar (approximately 180 kg of force).
• Throttle Mechanics: A robust die-cast aluminum arm combined with a 16-bit magnetic Hall sensor allows for smooth, high-resolution throttle feedback without mechanical wear.
• RGB LED Integration: Integrated lighting in the baseplate can be customized or turned off using Asetek’s RaceHub software.

The overall quality feels significantly more substantial and refined than most consumer-grade pedals, with aesthetics and mechanics inspired by the Pagani Huayra R itself.

Features & Adjustability

Brake Pedal – T.H.O.R.P System

The brake pedal is particularly noteworthy due to its hybrid hydraulic-elastomer design:

• Three Interchangeable Elastomers: Users can change the feel from softer to very firm, adjusting how quickly the hydraulic system engages.
• Manual Initial Touch Adjustment: This feature allows tuning of the initial pedal engagement before hydraulic force takes over.
• High-Pressure Sensor: It measures fluid pressure directly for consistent brake modulation in games.

This setup provides racers with precise control over brake feel and travel, simulating the short travel and firm feel characteristic of race cars.

Throttle Pedal

• Hall-Effect Sensor: Ensures frictionless, accurate throttle input detection.
• Adjustable Travel & Hardness: Users can modify spring and stop adjustments to fine-tune responsiveness.

Mechanical Tuning & Ergonomics

The pedal plate positioning is adjustable along the x- and y-axes for ergonomic comfort, although the footplates, inspired by the real car, are fixed in this edition. Both the brake and throttle pedals feature:

• Adjustable Stops & Preload: Settings can be adjusted without tools, allowing racers to find their personal sweet spot for pressure and feel.

Installation & Software

Installation is straightforward, aided by the included mounting hardware compatible with most rig setups. Once physically mounted, connection to a PC is made via a single USB cable, and the pedals are recognized as a standard input device by most racing simulations.

Asetek’s RaceHub software enhances functionality by enabling:

• Calibration: Allows fine-tuning of throttle and brake pedal response curves, along with adjusting dead zones.
• LED Customisation: RGB lighting colors and behaviors can be fully configured.
• Firmware Updates: Ensures compatibility and future enhancements.

Performance & In-Use Experience

On the track, the Pagani Huayra R Edition pedals deliver an exhilarating and immersive experience. The brake feels firm and responsive, with minimal travel before hydraulic engagement, which encourages later, more controlled braking — a hallmark of expert racing technique. The throttle action is smooth and proportional, aiding in precise modulation.

Adjustments to the pedals are intuitive and fast, allowing users to adapt the feel without the hassle of frequent disassembly. Many testers note that while this set is based on Asetek’s high-end Invicta pedals, it brings unique Pagani-specific styling and feel to the table without sacrificing performance.

Pros & Cons

Pros

• ✔ Premium Motorsport Build: Solid aluminum construction and CNC machining ensure resilience and an appealing aesthetic.
• ✔ Innovative Brake Feel: The T.H.O.R.P hydraulic system mimics a race car’s brake pedal, offering very firm feedback.
• ✔ Highly Adjustable: Pedal stops, preload, springs, and elastomers allow racers to customize their experience.
• ✔ Official Pagani Licensing: Unique branding and replica footplates from the Huayra R provide aesthetic exclusivity.
• ✔ RaceHub Software: Easy calibration and LED customization enhance usability.

Cons

• ✘ Price Point: Positioned at the high end, which may be beyond the budget of some sim racers.
• ✘ Fixed Footplates: Lack of height/angle adjustability on some parts might not suit all drivers.
• ✘ RGB Lighting Dependency: While visually appealing, LED features may be unnecessary for racers focused solely on performance.

Conclusion

The Asetek SimSports™ Pedal Set Pagani Huayra R Edition represents a top-tier sim racing pedal solution that seamlessly blends authentic hypercar design with cutting-edge mechanical performance. With its hydraulic T.H.O.R.P braking system, Hall-effect throttle, premium aluminum build, and extensive adjustability, it caters to sim racers seeking a true race-car feel and precise control from their pedal set. Whether you’re chasing consistent lap times or building a high-end sim rig with authentic real-car components, this pedal set delivers elite performance with a dash of Pagani flair.
